CSV Vibration Motor

Home>Products>Products>2 Pole>A-225

Products

A-225

Product Use

  • Preventing coagulation in materials storage bins and feeder conveyance pipes used by manufacturers.
  • Deal with powder and other tiny granular material in containers to load maximize capacity.
  • Dislodging dust and partialities into collectors to control air pollution.
  • Non-destructive vibration testing machines used in the computer and electronics industries.
  • Vibrating topple over concrete forms.
  • De-bubbling epoxy resin products such as PCBs. etc.

Size Chart


 Vibrator Speed

Power supply frequency of 50 Hz: 50Hz (3000 rpm)

Power supply frequency of 60 Hz: 60Hz (3600 rpm)


Models​ HP​ Vibrating force ​               Outer Dimensions (mm) Foot stand screw​

Weight (Kg)​
(Kg)​ D​

E​

F​

G​

H​

I​

J​

K​

L​

M​

N​

Φd​
A-225​ 1/3 360 190​ 180​ 90​ 13​ 100​ 200​ 50​ 57​ 325​ 230​ 170​ 18​ M16​ 23
