CSV Vibration Motor

Home>Products>Products>4 Pole>B-4220

Products

B-4220

Product Use

  • Preventing pipe clogging on small size materials storage tanks.
  • Deal with powder and other tiny granular material in containers.
  • Dual motor resonance-type bilge machines.
  • Materials conveyance and sandblasters in casting plants.
  • Vibrating liquid filtration machines for sludge.
  • Vibration-type electrostatic filters.
  • PVC granule sifting machines having a processing capacity.
  • Medium to small size conveyor and sifting machines.

Size Chart


Vibrator Speed
Power supply frequency of 50 Hz: 25Hz (1500 rpm)
Power supply frequency of 60 Hz: 30Hz (1800 rpm)

Models HP Vibrating force                 Outer Dimensions (mm) Foot stand screw Weight (Kg)
(Kg) D E F G H I J K L M N Φd
B-4220 3 5000 360 360 210 30 185 365 110 105 620 450 339 35 M33 212
